Wednesday 15 November 2017

Advanced Solar Energy in Space: Part I

Solar Thermal Rockets can be efficient and have high performance. However, they remain temperature-limited to an exhaust velocity of 12km/s.
How do we surpass this limit?
The limits

NASA's Suntower concept.
Solar Thermal Rockets have been shown to have great potential if we use modern materials technology - they can be as performant as Nuclear Thermal Rockets in the inner Solar System.

With Liquid Rhenium Solar Thermal Rocket, we demonstrated that it could be possible to increase the maximum operating temperature from the 4500K of the most advanced solid heat exchangers to the 5900K of a liquid rhenium-based heat exchanger. However, despite these high temperatures, a Solar Thermal Rocket can never exceed an exhaust velocity of 12km/s. Due to the second law of thermodynamics (the heat exchanger cannot get hotter than the source), the heat exchanger in a Solar Thermal Rocket cannot get hotter than the surface of the sun. As exhaust velocity depends on temperature, we cannot obtain more than 12km/s exhaust velocity out of a rocket that uses the Sun as a heat source.

Electric rockets
Solar Electric rockets are well known for powering propulsion systems with much higher exhaust velocities. The ion thruster on the Dawn probe was powered by 38m^2 of solar panels and achieved an exhaust velocity of 31.3km/s (3200s Isp).
A high exhaust velocity allows for the amount of propellant carried to be drastically reduced for any deltaV requirement. For example, if we wanted to go from Earth to Mars, the deltaV requirement is 6000m/s. A chemical-fuel rocket with an exhaust velocity of 3678m/s (375s Isp, like the Raptors on SpaceX's BFR) would need to consume 4.1kg of propellant for each 1kg of dry mass to fulfil the deltaV requirement. An ion thruster like Dawn's would only need 0.21kg for each 1kg of dry mass: a twenty-fold decrease.

In short, the main advantage of electric rocket is that they allow for very small spaceships that don't need a lot of propellant to go to further and faster.

So what's the catch?

Electric rockets have two major downsides.

The first is the power source. So far, we have used solar energy in the form of solar panels, or nuclear energy in the form of RTGs, to power electric rockets.

Solar panels have a fundamental efficiency limit called the Shockley–Queisser limit. It states that no more than 33.7% of the energy of sunlight can be extracted by a single solar cell. Most common solar cells have the potential to extract 32% of the Sun's energy using silicon band-gaps, while commercial versions manage an efficiency of only 24%. The world record for silicon solar panel efficiency is 26.3%.
An early Space-Based Solar Power concept.
Solar panels are rather heavy for their area and performance. They are usually several kilograms per square meter. Research into making solar panels lighter has produced designs such as thin-film solar cells with 0.2 or even 0.1kg/m^2.

Combining the efficiency of the most advanced solar panels with the sectional density of thin-films solar cells makes for a system with a power density of 1.5kW/kg at most. Modern advanced solar cells for spacecraft aim for 0.3kW/kg

Other power options rely on nuclear energy. The current form of nuclear energy of spacecraft, RTGs, has woefully poor performance. A power density of 1 to 10W/kg is to be expected.
The SP100 nuclear reactor.
Nuclear reactors with a carnot heat cycle (Stirling heat engine, steam turbines and so on) have great potential, but currently they are limited by the low temperature difference between the reactor core and the radiators. This is the result of having to keep the fissile fuels inside the reactor core solid and safe (so a low maximum temperature) and the low performance of thermal radiators currently employed (so a high minimum temperature). Despite these limitations, nuclear reactors producing over 10kW/kg have been designed. They have a potential of over 100kW/kg or more.

Nuclear power has problems not related to its performance as well. For the foreseeable future, fissile fuels are expensive, dangerous to handle and a hot-button political and environmental topic. The radioactivity continuously degrades the power generating equipment and makes refurbishment or repairs a complicated affair. A lot of effort will have to be put into finding sources of fuels if we intend to exploit the Solar System, otherwise we'd have to wait for alternative nuclear technologies such as fusion reactors to mature.
Low power density means low acceleration. Spiralling trajectories are the result.
The second problem with electric rockets is their low propulsive power.
One aspect is that the electrical power divided by the exhaust velocity leads to a very low thrust output. Another aspect is that the cryogenic magnets, the superconducting coils, the electrostatic chambers... are simply quite heavy. Current laboratory-tested concepts such as VASIMR are only expected to have about 1kW/kg, with most other designs struggling to reach ten times less specific power.
Between the two, electric rockets end up having extremely low thrust. This prolongs the burns that chemical rockets can perform in minutes into weeks-long affairs that spend an inordinate amount of time in Earth's Van Allen belts. The benefits of the Oberth effect are completely lost and gravity losses that come from accelerating away from the optimal angle become significant. Reducing the duration of these burns requires dedicating most of the spacecraft's dry mass to power generation and propulsion, so as to increase the rate of accelerations. The propellant to payload ratio quickly drops to levels comparable to chemical propulsion.

Advanced Solar Electric Energy

We need to improve the performance of electric rockets. It is possible to do this without relying on problematic nuclear propulsion, limp solar panels or the massive amounts of chemical fuels needed for interplanetary travel.

What we need is advanced solar energy concepts with much higher power densities. We will now look at designs that allow the efficient use of sunlight to produce electricity out of compact and lightweight generators

They common key to these designs' performance is the use of solar collectors made of extremely lightweight materials, based on the technology developed for solar sails. These reflective surfaces of only a few grams per square meter can focus huge amounts of sunlight onto a small surface. Intense sunlight allows for higher performance and greater temperatures.

Concentrated photovoltaics

Photovoltaics convert the light they absorb into electricity. By increasing the intensity of this light, more electricity can be produced from the same solar cell. This increases power density. Peak gains are obtained from x1000 -x3000 concentration.

Concentrated photovoltaics attempt to multiply the intensity of sunlight collected by a solar panel by adding a concentrator. A concentrator focuses sunlight onto the solar panel's surface. Since the concentrator only needs to be reflective, it can be much lighter than an equivalent surface area of solar panels. By maximizing the collector area (lightweight) and minimizing the solar cell area (heavy), a better power density can be achieved.

On top of simple mass optimization, efficiency can be improved. Conventional solar cells use a single silicon p-n junction. The efficiency therefore capped by the the Shockley-Queisser limit. This is sufficient as the design is cheap and relatively lightweight, so higher output is achieved by adding more solar panel area.

Doped silicon solar cell.
Concentrated photovoltaics leads to a very small solar panel surface area. It becomes more reasonable to use more complex solar cells that improve efficiency. Multijunction solar cells use multiple p-n junctions on top of each other. Each p-n junction is tuned to a portion of the electromagnetic spectrum. Sunlight ranges from radiations in the infrared to X-rays. Only 47% of sunlight's energy is contained in the narrow portion of the electromagnetic spectrum called the visual spectrum, that corresponds to radiations of wavelengths 400 nanometers to 700 nanometers. Conventional solar cells only absorb a fraction of this small segment.
Red, green and blue p-n junctions capture energy from wavelengths that correspond to the low (infrared to red), middle (yellow and green) and high energy (blue to UV) sunlight.
Triple junction solar cell. Up to 50% efficiency.
Quadruple junction solar cell extending into the deep IR wavelengths. Better suited for space use. Up to 56% efficiency.
By increasing the number of junction layers and dividing light received into small slices corresponding to each layer, a theoretical maximal efficiency of 86.8% is possible. The number of layers for each efficiency improvement increases exponentially.  Reaching 86.8% efficiency requires an infinite number of layers. By three layers, the efficiency cap is raised to 63%, which we will deem sufficient. Another concern is heating. The sunlight that is not converted into electricity becomes waste heat instead. Increasing the temperature of a solar cell lowers its efficiency. When concentrators are focusing sunlight to tens to hundreds of times its normal intensity, the heating can quickly become problematic.

Active cooling is therefore required to keep concentrated photovoltaics cool and efficient for space applications.

In the above graph, a solar cell under 1000x sunlight intensity is tested at a range of temperatures. At 400K, it is estimated that there is an efficiency loss of 11% of the value at 280K. Lower temperatures improve the rate at which photons are converted in the semiconductors, prevent losses from re-radiated energy and lessen the effect of other inefficiencies such as recombination.
Another study cooled down solar cells down to 50 Kelvins. The graph above is the theoretical maximal efficiency achieved at each temperature. We notice that at 50K, the peak efficiency (41%) is 37% higher than the peak efficiency at 300K (30%).

Three-junction solar cells can have a mass of 0.85kg per square meter or less. In this book, 0.1kg/m^2 is cited for a concentrated solar cell array, although it cannot be determined if it is multi-junction. This recent NASA proposal for concentrator quadruple-junction solar cells designed to survive extreme environments cites 0.24kg/m^2 as the figure for solar cells without their concentrators.

Let us now consider two designs for modern or advanced multi-junction concentrator solar energy systems. We note that waste heat management is a determinant factor in the potential performance of these designs. Refer to All the Radiators for more details.

Modern concentrated photovoltaic example:

Different solar concentrator configurations.
We will use conservative figures. 0.85kg/m^2 for the solar cells, with quadruple junctions operating at room temperature (300K) to provide an efficiency of 40%. The concentrator is a parabolic dish of mass 7g/m^2 and a reflectivity 95%. The solar concentration is x1000.

1.29MW of solar energy is focused by 1000m^2 of concentrator onto each 1m^2 of solar panel. It is converted into 519kW of electricity and 779kW of waste heat.

The waste heat must be dealt with using a lightweight, low temperature radiator.

A liquid droplet radiator is ideal for this task. 0.1mm wide droplets of bromine coated in black paint, spaced by 0.5mm and released at a velocity of 1m/s across a 1m wide gap would cool down from 300K to 283K before being captured as solid mercury balls. The radiators would remove 10.4W of heat for every 1m^2 of droplets. The power density of the radiator is 4.6kW/kg.

The component masses for 1m^2 are 0.85kg of solar panels, 7kg of collectors and 169kg of radiators. It produces 519kW.

The system power density becomes 2.9kW/kg. A more realistic figure would include the mass of additional systems such as power converters, droplet radiator booms and pumps, solar tracking mechanisms for the collectors and so on, probably bringing down the system power density to 2.5kW/kg

Advanced concentrated photovoltaic example:

Graphene foam can form the basis for ultra-lightweight solar collectors.
We will use optimistic figures. 0.25kg/m^2 for quadruple junction solar cells operating at a 353K temperature. The efficiency is 60%. Micron-thick aluminium concentrators resting on graphene foam or tensed by Zylon wires have a mass of only 1 gram per square meter. Reflectivity is 95% and solar concentration is 10000x.

13MW of sunlight reach the solar cells. 7.79MW becomes electricity while 5.19MW becomes waste heat.

An 90% efficient heat pump will be needed to increase the radiator's temperature and improve the overall power density. Based on the Brayton turbopumps used in the Space Shuttle's SSME's, we can expect 150kW/kg from these heat pumps.
Turbo expander-coolers are in use today.
Increasing the waste heat's temperature from 353K to 700K will require 1.1W of electricity be consumed for every 1W of heat moved. The heat pump will consume 5.7MW and mass 38kg.

We will use a hybrid wire/droplet radiator.

The wires can have alternating hydrophobic and hydrophilic surfaces.
Small droplets of sodium are held by charged surfaces, alternating hydrophobic/hydrophobic patches or simple surface tension, on a thin wire. The wire drags the droplets along like a conveyor belt. Each 1m^2 of radiator area is composed of 1000 parallel wires holding droplets of 0.1mm diameter each, moving along at 10m/s. The utility of this design is that the droplets can be held very close together (0.1mm).
The passage through the vacuum cools the droplets from 700K to 624K. The high heat capacity of water means that more than 4027W of heat can be removed by 1m^2 of water and wires. That surface allows for a power density of 64.6kW/kg.

The component masses are 0.25kg of solar panels, 10kg of concentrators, a 38kg heat pump and 80kg of radiators. System power density can approach 16.3kW/kg

Even more advanced designs that use thinner reflectors, faster wire/droplet radiators and lower temperature (higher efficiency) solar cells can probably reach 20kW/kg

High temperature thermophotovoltaics

Photovoltaics are most efficient when converting light composed of wavelength exactly matching the band-gap of the n-p junction materials they are composed of.

This is what allows laser-to-electrical conversion to achieve very high efficiencies. The wavelength of the laser exactly matches the band-gap of the converter.

We cannot expect such efficiencies using the Sun's broad spectrum of radiations. Even multi-junction solar cells can only cover part of the spectrum, at the cost of greater complexity, cost and mass per square meter.

Using different receiver/emitter materials helps specify which wavelengths reach the PV cell
There is a solution in tuned thermo-photovoltaics. In this design, the Sun's rays are focused on a heat exchanger. The heat exchanger absorbs the entire solar spectrum and radiates it back in a narrower range of wavelengths. Selective filters reflect anything outside of an even narrower selection of wavelengths back to the heat exchanger so that the energy is not wasted.

A heat exchanger combined with efficient filters allows us to reduce the solar spectrum to emissions exactly matching the band-gap of a solar cell. Efficiencies of 98% of the maximum thermodynamic efficiency are possible using a single n-p junction.

TPV system with optical concentrator.
Currently, thermophotovoltaics are limited by the stability of the heat exchanger, the loss of re-radiated energy, the lack of cooling systems and simple lack of development when compared to traditional photovoltaics. For example, most designs tested today focus on Silicon Carbide or Tungsten heated to 1500K, while the thermophotovoltaic cells reach 350K or more. The maximal thermal efficiency becomes 76%. From this amount, 20 to 50% of the radiations from the heat exchanger are lost or simply go in the wrong direction in typical flat heat exchanger designs. Solar cells operating at high temperature, losing efficiency compared to their counterparts at 300 or 270K. The radiations outside the band gap range of wavelengths are not always efficiently recycled back into the heat exchanger too. Finally, the low temperature emitters cannot achieve the high emission intensities (MW/m^2) that have helped the efficiency of concentrated solar photovoltaics.

A solution to these problems can be found.

Hot tungsten coils.
Using higher-temperature heat exchanger materials is a start. Carbon is ideal, with a melting temperature of over 4000K. Tungsten can reach 3000K temperatures without a problem.

Instead of using small band-gap p-n junctions such as Gallium Arsenide, Silicon with a band gap of 1.1eV, which corresponds to wavelengths of 1100nm, can be selected. This corresponds to the peak emissions of an emitter at 2660K. Active cooling can handle the heat load to reduce the cold end temperature to 270K. The thermal efficiency of system with a 2660K hot end and 270K cold end is 89%. This is an immediate 13% improvement over current systems.

A photonic crystal composed of layers of gallium arsenide and air with an otherwise impossible band gap.
Even more recent research focusing on artificial band-gaps created by using photonic crystals permits efficiencies greater than 40%
The configuration of a cylindrical heat exchanger absorbing sunlight from surfaces on the ends.
The heat exchanger can be shaped into a very long cylinder inserted into a closed chamber. The chamber's inner walls are coated with TPV cells. Sunlight concentrators focus sunlight onto the exposed top and bottom of the cylinder. The cylinder then re-radiates this heat from the enclosed lateral walls onto the TPV cells. It is called a 'thermal well'. The large exposed to enclosed surface area ratio of the cylindrical heat exchanger means that very little of the heat exchanger's radiations are lost. This is another 20-50% improvement over current designs.

A good optical filter is needed. For silicon, a filter would need to only allow wavelengths longer than about 800nm or shorter than 1100nm. This is possible today with developments in nano-structured metamaterials and photonic crystals.

Finally, as demonstrated in the previous section, it is possible to gain a 20% increase in efficiency or more by cooling the solar cells.

Together, these optimizations can achieve the 50% efficiency purported in recent research, or approach 70 to 80% efficiency as dictated by theoretical limits.

We will now look at a modern, then advanced, design for a solar TPV system.

Modern thermophotovoltaic example:

We will only use figures available in today's research.
High temperature thermo-photovoltaic device.
We use a tungsten heat exchanger, heated to 3000K. The thermophotovoltaics are indium-gallium-arsenide-phosphide cells with a bandgap tuned exactly to the peak emissions of the heat exchanger, for an efficiency of 61%. The n-p junction is only 50 nanometers thick and backed by a silver plate to reflect unabsorbed wavelengths back to the heat exchanger.
Blackbody emission spectrums for various temperatures.
The heat exchanger will be a carbon-coated cylinder. Sunlight is focused onto its flat ends. The light is absorbed and heats up the tungsten. Heat conducts down the cylinder and is re-radiated out of the lateral surfaces. A shell of solar cells intercepts these radiations. At 3000K, the tungsten is emitting at 4.1MW/m^2 but only 1.15MW/m^2 reaches the solar cells. This means that for each square meter of tungsten, there will be 3.56 square meters of solar cells.

The thinner the heat exchanger, the lighter it can be. A 10cm wide, 1m long tungsten cylinder would mass 153.8kg and have a lateral surface area of 0.31m^2. It will be able to illuminate 1.1m^2 of solar cells. The mass of tungsten per square meter of solar cell becomes 139.8kg. If we use a 1cm wide cylinder instead, we calculate a tungsten mass of just 14 kg per square meter of solar cells. We will use the latter figure. Another benefit is that the radiations lost from the cylinder ends amount to only 0.25% of the total radiations.

The full radiation of the heat exchanger's lateral surfaces will have be matched by an equivalent input from its top and bottom surfaces. For a 1cm wide rod, this means that 0.031m^2 of lateral surface area are supplied by 1.57cm^2 of illuminated area; a ratio of 395:1. The solar concentrators are therefore heating the tungsten at an intensity of 1632MW/m^2.

95% reflective solar concentrators would be achieving a concentration of x628399. If the tungsten rod is I-shaped, with larger absorbing surfaces at the top and bottom, the radiative efficiency is lessened but the concentration factor becomes more manageable. If a 10% radiative loss is acceptable, the a concentration factor of 'only' x15710 is needed. At 7g/m^2, about 0.68kg of reflective concentrator surfaces would be needed to heat a 1cm and 1m long wide tungsten rod. This represents about 0.61kg per square meter of solar cells.

Plasmonic light-trapping nanoparticles help very thin solar cells capture as much light as thick solar cells.
As this is a single-layer solar cell, we can use the masses of thin-film solar cell arrays as a basis for our power density calculation. This means 0.2kg/m^2 or less. A silver backing plate and a denser semiconductor mix might mean an area density closer to 1kg/m^2. They convert the radiations into 631.3kW of electricity and 403.7kW of heat.

The solar cells must be kept at 300K. Cooling will rely on the mercury droplet radiator mentioned above. 88kg of droplets are required to remove the waste heat.

Component masses come out as 1kg for the solar cells, 14kg for the heat exchanger, 0.61kg for the solar concentrator and 88kg for the droplets.

System power density is 6.1kW/kg, although other components we have not considered might lower this somewhat.

Advanced thermophotovoltaic example:

Advanced materials technology and miniaturization techniques can drastically increase the system power density of thermo-photovoltaics.
Photoluminescent emitters allow short wavelength radiations without the need for high temperatures.
Indium gallium phosphide, typically used as the 'blue cell' in a multi-junction solar panel, will be our only layer. It operates best when it receives 545nm wavelength light. This light will be supplied by a 5317 Kelvin blackbody, with metamaterials filtering out wavelengths too long to be efficiently converted by the solar cell. The solar cells have an 80% conversion efficiency of light at 10MW/m^2 intensity, while massing only 0.1kg/m^2.
The lightbulb structure needed to contain the liquid rhenium.
The heat exchanger will be liquid rhenium, held inside a transparent tube of fused quartz. The tube walls are actively cooled by circulating hydrogen gas in a manner similar to what was proposed for Closed-Cycle Gaseous-Core Nuclear Thermal Rockets, or 'nuclear lightbulbs'. An alternative would be electromagnetically contained plasma, such as cesium ions.

Non-imaging optics allow for extreme solar concentration ratios with sub-1% radiative losses.

Parabolic compound troughs can also reduce the sun-tracking requirements of the solar collectors.
The liquid rhenium heat exchanging cylinder will be 2mm wide. It masses only 66 grams per meter length. Heat is absorbed from end-caps 6.3mm wide, giving it an I-shape. The tube radiates at 40.78MW/m^2 and receives 4078MW/m^2 through the end caps. Each tube shines on 0.0256m^2 of solar cells, so it adds 2.57kg per square meter of solar cells.
Sunlight is supplied by 197m^2 of 95% reflective solar collectors. At 1g/m^2, the solar collectors would mass about 0.2kg.

Each square meter of solar cells produces 8MW of electricity but also 2MW of waste heat.

We use the heat pump and sodium wire arrangement of radiators from the advanced version of the concentrated sunlight generator to handle this.

It would require a 2.2MW heat pump massing 14.7kg, and 30.96kg of radiators.

Component masses are 0.1kg for the solar cells, 2.57kg for the heat exchanger, 0.2kg for the solar collectors, 14.7kg for the heat pump and 30.96kg for the radiators. System power density should be close to 119kW/kg, though realistically it will be lower.

Part II

In the second part of this series, we will look at power generation options that do not rely on photovoltaics.
